32 X 40 House Plan - 1280 Sq Ft House Plan And Elevation Design - HP1045

Key Features of This Plan

  • Layout
    32 x 40 sq ft

  • Plot size
    1280 sq ft

  • Build area
    1808 sq ft

  • Facing
    East

  • Floors
    2

  • Bedrooms
    4

  • Bathrooms
    4

  • Car Parking
    Yes

  • Open Terrace
    No

  • Lift
    No

  • Approx build cost
    2164800

Plan Description

Planning to build a duplex house and looking for a 32 x 40 sq ft House Plan? Check this beautifully designed 32 x 40 east facing duplex house plan to get inspiration. The houseyog Architects have designed this 1280 sq ft east facing duplex house floor plan and elevation designs for one of our esteemed customer in Lucknow, Uttar Pradesh.

The 1280 sq ft house plan has been designed for a 32 by 40 sq ft east facing plot of land. This duplex house design has the total built up area of around 1808 sq ft. Both the floors has a built up area of around 904 sq ft.

This modern and luxurious Vastu house design features 4 bedrooms, 4 bathrooms, living, dining and a good size Kitchen. On the ground floor of the house, we have also provided a covered car parking space and landscaped lawn. On the first floor we have provided an open terrace area that can be used as a sit out area and can be decorated with potted plants.

The ground floor of this house has been designed for rental purpose, and therefore the plan features one shop, one bedroom, an open kitchen and living cum dining area. There is one common toilet, one attached toilet and a utility space as well. The ground floor plan in this 32 x 40 Vastu house plan design also features a covered car parking space and a lawn. There is a separate entry to the ground floor, and we have kept the staircase outside that leads to the first floor of the house.

The first floor in this house design is primarily for the home owner, and it features 3 bedrooms, one open kitchen, 2 bathrooms (one attached), one utility room and one store room. We have also provided an open terrace of around 230 sq ft which can be used as a sit out area.

The elevation for this 32 x 40 sq ft Indian style duplex house design is very modern and luxurious. We have designed two different elevation design variations for this building. One of the elevation design features glass exterior finish near the staircase and other is normal brick wall with tiles finish from outside. Both the exterior elevation designs looks just fantastic and we can't wait to see this building coming to life and host our client.

If you are looking for a modern and luxurious 23 by 40 East facing Vastu house plan and wondering where to find the best Architects in Lucknow Uttar Pradesh to design such beautiful homes, then feel free to call us now. We offer end to end house designing and architect service in Lucknow, Varanasi, Prayagraj and other cities across UP, Punjab, Haryana, Bihar, Jharkhand, Odisha, West Bengal an other states in India.

Plan Specification

Ground floor build area: 904 sq ft approx. Features one Shop at the front, one bedroom with attached toilet, one bathroom, open kitchen, living cum dining hall, covered car parking, utility space and front side open lawn.

  • Bedroom
    1

  • Hall
    Yes

  • Kitchen
    1

  • Attached Bathroom
    1

  • Common Bathroom
    1

  • Study
    No

  • Temple
    Yes

  • Utility space
    Yes

  • Swimming pool
    No

  • Garden
    Yes

  • Car Parking
    Yes

First floor plan has the built up area of approx 904 sq ft. Features 3 bedrooms, one store room, open kitchen, two bathrooms and a wide open terrace which can be used for sit out and potted plantation.

  • Bedroom
    3

  • Kitchen
    1

  • Attached Bathroom
    1

  • Common Bathroom
    1

  • Study
    No

  • Temple
    No

  • Balcony
    1

  • Utility space
    Yes

  • Swimming pool
    No

  • Garden
    Yes

  • Car Parking
    No

House Plan and Elevation Images

Ground floor plan
Ground floor plan
First floor plan
First floor plan
House Elevation - Front View
House Elevation - Front View
House Elevation - Side View
House Elevation - Side View

Design style: Contemporary, Duplex, Indian, Luxury, Modern

Last updated on: 24 May 2021

What's included in complete plan set?

Download a sample plan set

  • Space optimized floor plan with measurements
  • High definition 3D front elevation design
  • Structural and Working drawings
  • Drainage and plumbing blue print
  • Electrical and circuit drawings

This plan design can be customized!

This house plan design can be customized to meet your requirements. If you liked this plan and need cosmetic changes, then please tell us about your desired changes and we’ll help you get it right. Click the button to tell us your customization needs, or call 75960 58808.

Modify This Plan

Buy This Plan and Start Building

All house design plans and packages includes free customization and changes.

Order this plan now, and get it modified without paying any customization charges.

Basic: Plan and Elevation Design

10120

House plan drawing
Building elevation design
--
--
--
--
--
--

Most Popular

Complete: Plan, Elevation and Drawings

18900

House plan drawing
Building elevation design
Structural drawing
Working drawing
--
--
--
--

Full Set: Plan, Elevation and complete drawings

25180

House plan drawing
Building elevation design
Structural drawing
Working drawing
Drainage drawing
Electrical drawing
Plumbing drawing
A3 size printed plan set
